Hot sale 40-120 ton low price China low bed trailers - Best semi trailers from China
China low bed trailers directly sale from factory,
1. China top quality factory
2. Fast delivery time in 20 days
3. All famous brand parts
4. Heavy duty load capacity and long service life
5. Professional shipping service
China low bed trailers 40-120 ton specification,
Product Name | 4 axles 16 wheels China low bed trailers |
Dimension(Lx W x H)（mm） | 12500/13000/14000/16000×2500/3000×1100/3300mm or customizable |
Tare weight (kg) | 9500 (depends on final configuration) |
Max Loading Capacity (kg) | 60000 （customizable) |
Main Beam | Q345B / T700 Steel upper plate is 16mm, down plate is 18mm, middle plate is 12 mm (customizable) |
Side Beam | 20# channel steel (customizable) |
Bottom Plate | 4mm diamond plate (customizable) |
Wheel base mm） | 8580+1310+1310 |
Axles | 13/16/20 Ton. Axle amount optional like 2/3/4/6axles …, Axle brand optional like SAF /FUWA/BPW etc |
Tire | 12.00R22.5/315 80R22.5/11.00R20/12.00R20(Brand optional) |
Rim | 9.00-22.5/8.00-20/8.50-20 |
King Pin | 2″(50mm)or3.5″(90mm) JOST or other brand optional |
Suspension | Mechanical Suspension Air Suspension(American or German) |
Leaf Spring | 90(w)mm*13/16(thickness)mm*10(layer) |
Landing Gear | 28t Heavy Duty Landing Gear. Brand optional FUWA/JOST etc. |
Twist-lock | 4/8/12 units (customizable) |
Brake System | Dual line brake system, Air chamber T30/30, 3 X 40L gas storage drums |
ABS System | None or installed as your requirement. |
Electrical system | 1. Voltage: 24v waterproof 2. Receptacle: 7 ways (7 wire harness); LED light ( standard rear light, turn light, rear reflector, side light, side reflector etc.) |
Color | As per customer requirement |
Spare Wheel Bracket | Two set of heavy duty spare wheel carriers, including a riser |
Tool box | 1 set of standard tool box equipped with 1 Tire spanner, 1 gudgeon sleeve and 1 cranking bar |
Painting | Sand blasting before painting; one coats of primer, anti- corrosion; two coat of finish painting; |
Packing | Wax painting treatment to protect the vehicles from sea water, and the chassis greased to avoid rusting during shipping. |
Delivery | From China port, and carry by container ship, ro-ro ship or bulk ship, the freight cost depends on the volume. |
Remarks | Our senior engineer can design semi trailer as your request, and we accept OEM/ODM projects. |
